410 stainless steel

Chemical Composition (%) of 410 Stainless Steel Plate

C	Mn	Si	P	S	Cr	Ni
0.15	1.0	1.0	0.04	0.03	11.5-13.5	0.5

Mechanical Properties of 410 Stainless Steel Plate

Tensile Strength MPa (min)	Yield Strength 0.2% MPa(min)	Elongation %	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
450	205	20	217	96

Physical Properties of 410 Stainless Steel Plate

Density lb_m/in³	Thermal Conductivity (BTU/h ft. °F)	Electrical Resistivity (in x 10^-6)	Modulus of Elasticity (psi x 10⁶	Coefficient of Thermal Expansion (in/in)/ °F x 10^-6	Specific Heat (BTU/lb/ °F)	Melting Range (°F)
at 68°F: 0.276	14.4 at 212°F	56 at 68°F	29	5.90 at 68 – 392°F	0.11 at 68°F to 212°F	2700 to 2790

Alloy 410 is the basic, general purpose martensitic stainless steel that is used for highly stressed parts and provides good corrosion resistance plus high strength and hardness. Alloy 410 contains a minimum of 11.5% chromium which is just sufficient enough to demonstrate corrosion resistance properties in mild atmospheres, steam, and many mild chemical environments.

It is a general purpose grade that is often supplied in the hardened but still machineable condition for applications where high strength and moderate heat and corrosion resistance are required. Alloy 410 displays maximum corrosion resistance when it’s been hardened, tempered, and then polished.
