405 stainless steel supplier

Chemical Composition (%) of 405 Stainless Steel Plate
Cr Ni C Si Mn P S AI
11.5-14.5 0.50 0.08 0.03 1.0 0.04 0.03 0.1-0.3
Mechanical Properties of 405 Stainless Steel Plate
Tensile Strength ksi (min.) Yield Strength 0.2% Offset ksi (min.) Elongation - % in 50 mm (min.) Hardness (Rockwell B) MAX
60 25 20 88
Physical Properties of 405 Stainless Steel Plate
Denstiy lbm/in3 Coefficient of thermal Expansion (min/in)-°F thermal Conductivity BTU/hr-ft-°F Specific Heat BTU/lbm -°F Modules of Elasticity (annealed)2-psi
at 68 °F at 68 – 212°F at 68 – 1450°F at 200°F at 32 – 212°F in tension (E)
0.279 9.2 20.5 416 0.11 28 x 106

Alloy 405 is a 12% chromium stainless steel designed to be used in the as-welded condition. Unlike the other grades of 12% chromium stainless, 405 is not vulnerable to extensive hardening through air cooling from high temperatures. Applications that frequently use alloy 405 include, but are not limited to:

  • Steam nozzles
  • Partitions
  • Annealing boxes
  • Quenching racks
  • Fabrications that cannot be annealed after welding
If you are interested in other Stainless Steel Plates/Sheets, please click 302, 303, 304, 304L, 304H, 309, 309S, 310, 310S, 310H, 316, 316L, 317/317L, 317LMN, 321, 321H, 330, 347, 347H, 904L, 403, 405, 409, 410, 410S, 410/HT, 416, 416HT, 420, 422, 430, 440C, Duplex 2205, Duplex 2304, Duplex 2507.
